Parts Identification
PARTS IDENTIFICATION
1. Headlight
2. Front indicator
3. Windscreen adjuster, left hand side
4. Fuel tank and fuel filler cap
5. Battery and fuse boxes
6. Tool kit/Accessory U-lock storage
location
7. Rear indicator
8. Seat lock
9. Rear brake caliper
10 . R e a r b r a k e d i s c
11. C e n t r e s t a n d
12. Gear-change pedal
13 . S i d e s t a n d
14. Coolant expansion tank
15 . R a d i a t o r c o w l
16. Front brake caliper
17. Front brake disc
1
2
4
5
67
8
11
12
131516
17
14
3
910
