59
General Information
Rider's Seat
1. R i d e r ’ s s e a t
To remove the rider’s seat, remove the rear
seat (see page 58).
Grasp the rider’s seat on either side, and slide
it rearwards and upwards for complete
removal from the motorcycle.
To refit the seat, engage the seat's front rail
into the bracket at the rear of the fuel tank
and lower the rear rail in to the rear brackets.
Push down firmly on the rear of the seat. Refit
the rear seat (see page 58).
Rider’s Seat Height Adjustment
1. R i d e r ’ s s e a t
2. Front height adjuster
3. Rear height adjuster
4. Low seat height position (front
shown)
5. High seat height position (front
shown)
The rider’s seat is adjustable for height by
approximately 20 mm.
To adjust the rider’s seat:
Remove the rider’s seat (see page 59).
Reposition both seat height adjusters to the
higher or lower position as required. Ensure
both adjuster rails are fully engaged in their
brackets on the seat.
Refit the rider’s seat (see page 59).
The rider’s seat is only correctly retained
and supported once the rear seat is
correctly fitted. Never ride the motorcycle
with the rear seat detached or removed, as
the front seat will not be secured and may
move.
A loose or detached seat could cause loss
of motorcycle control and an accident.
