36
General Information
Warning Lights
Note:
• When the ignition is switched on,
the instrument warning lights will
illuminate for 2 seconds and will
then go off (except those which
remain on until the engine starts, as
described in the following pages).
Direction Indicators
When the indicator switch is
pushed to the left or right, the
turn indicator light will flash on and off at the
same speed as the turn indicators.
High Beam
When the ignition is switched on
and the headlight dip switch is set
to 'high beam', the high beam
warning light will illuminate.
Low Fuel
The low fuel indicator will
illuminate when there are
approximately 4.5 litres of fuel
remaining in the tank.
Neutral
The neutral warning light
indicates when the transmission is
in neutral (no gear selected). The
warning light will illuminate when the
transmission is in neutral with the ignition
switch in the ON position.
Low Oil Pressure Warning Light
With the engine running, if the
engine oil pressure becomes
dangerously low, the low oil pressure
warning light in the tachometer will illuminate
and 'oil Pr' will also be visible in the display
screen.
1. Oil pressure warning light
2. Display area, oil pressure shown
Stop the engine immediately if the low oil
pressure warning light illuminates. Do not
restart the engine until the fault has been
rectified.
Severe engine damage will result from
running the engine when the low oil
pressure warning light is illuminated.
MIN
-1
x 1000
2
1
