66
General Information
Check:
Fuel: Adequate supply in tank, no fuel leaks
(page 54).
Engine Oil: Correct level visible at sight
glass. Add correct specification oil as
required. No leaks from the engine or oil
cooler (page 90).
Final Drive: No oil leaks (page 98).
Tyres/Wheels: Correct inflation pressures
(when cold). Tread depth/wear, tyre/wheel
damage, punctures etc. (page 10 8 ).
Nuts, Bolts, Fasteners: Visually check that
steering and suspension components, axles,
and all controls are properly tightened or
fastened. Inspect all areas for loose/damaged
fixings.
Steering Action: Smooth but not loose from
lock to lock. No binding of any of the control
cables (page 10 2 ).
Brakes: Pull the brake lever and push the
brake pedal to check for correct resistance.
Investigate any lever/pedal where the travel is
excessive before meeting resistance, or if
either control feels spongy in operation
(page 99).
ABS: Ensure that the ABS warning light does
not remain illuminated at speeds above
6 mph (10 km/h) when moving off
(page 38).
Brake Pads: There should be more than
1.5 mm of friction material remaining on all
the pads (page 99).
Brake Fluid Levels: No brake and clutch
fluid leakage. Brake fluid levels must be
between the MAX and MIN marks on both
reservoirs (page 101 ).
Front Forks: Smooth action. No leaks from
fork seals (page 10 4 ).
Throttle: Throttle grip free play 2 - 3 mm.
Ensure that the throttle grip returns to the
idle position without sticking (page 49).
Clutch Fluid Level: No brake and clutch
fluid leakage. The clutch fluid level must be
between the MAX and MIN marks on the
reservoir (page 97).
Coolant: No coolant leakage. Check the
coolant level in the expansion tank (when the
engine is cold) (page 93).
Electrical Equipment: All lights and the
horn function correctly (page 41 ).
Engine Stop: Stop switch turns the engine
off (page 68).
Stands: Returns to the fully up position by
spring tension. Return springs not weak or
damaged (page 56).
