Do not place the print-unit on any sides, other than horizontally.
Do not tilt the unit
3.2 Pre-requisites
1. Mail table (MT1 or MT2)
2. T3 OPX bracket system (for 600mm or 1000mm wide tables)
3. Allen key set 2.5 - 6mm
4. C-clip pliers
3.3 MailTable 1 or 2 setup
The process for the mailtable 1 and 2 is identical.
1. Place the table upside down
a. Place it on a mat or similar to protect the belts
This step requires heavy lifting, ensure lifting equipment or extra personal is present to
move the table (Check local rules and regulations). See chapter 1.5.5 or 1.5.6 for weight
specifications.
