TrojanTwo User Guide v3.8
When the button is pressed the green LED will flash fast and when sensor is adjusted the red LED
will go off and green LED will stay lit constantly.
When moving a label (not gap) into the sensor beam the red LED will go on indicating that the
sensor can differentiate between gap and label.
IMPORTANT: Because of inter-page actions the printed labels have to have:
Minimum 2.2 mm gap at 6IPS mode
Minimum 3 mm gap at 12IPS mode.
Maximum gap size is 65 mm
IMPORTANT: Setting label gap outside the minimum and maximum range can result to label skipping,
missed TOF error message or enormously high label gaps.
