TrojanTwo User Guide v3.8
17 Slitter for the TrojanTwo
17.1 Purpose
The slitter option is an in-line slitter that works perfectly with die cut label material. Slit up to four (4) rolls,
with the three (3) easy to replace oscillating blades that ensures long life time and perfect cuts. The blades
can placed in any position or moved to the side when not in use.
The slitter is an optional accessory for the TrojanTwo press and not included by default.
NOTE: As the slitter was introduced at late 2015, the earlier batches of TrojanTwo presses do not contain
the fitting holes for installing the slitter components. The solution can be retrofitted, but it does require
drilling two holes. The remainder of the system fits into the current architecture.
The new batches from late 2015 are prepared for installing the slitter at any time.
17.2 Safety Labels
There are two warning signs need to be put on to the TrojanTwo press when the slitter is installed:
