Every time when a tuning is completed the system stores the actual
pitch for each string. On re-tune the system checks if the actual string
frequencies are within a certain PITCH WINDOW. If a string is outside its
Pitch Window the corresponding LED turns purple. If at least one string
is out of its Pitch Window the system turns automatically to SINGLE
TUNE MODE after the remaining strings are tuned.
The Pitch Window can be adjusted from 25 to 150 Cent.
PITCH WINDOW
e B G D A E
25 35 50 75 100 150
PRESS “LEFT/RIGHT“ for desired PITCH WINDOW.
PRESS “ENTER“ to confirm.
EXAMPLE:
THE PITCH WINDOW IS SET TO 100CENT=5LEDS. THE LAST
COMPLETED TUNING WAS A STANDARD EADGBE. NOW THE
SYSTEM IS STARTED AGAIN. IF THE PITCH OF THE LOW E STRING IS
MORE THAN 100CENT OFF, THE CORRESPONDING ELED WOULD
BECOME MAGENTA LOWER THAN EB OR HIGHER THAN F.
E
E
A
A
DG
DGB
