5.6.4 Dry mortarless installation with installation kit GL
①
②
③
④
Fig. 22: Installation into lightweight partition wall with flexible ceiling joint, using dry mortarless installation kit GL
①
Solid ceiling slab
②
Lightweight partition wall
③
FKRS-EU
④
Installation kit GL
Personnel:

Specialist personnel
Requirements
 Performance class EI 90 S
 Lightweight partition walls with metal support structure and cladding on both sides, W ≥ 100 mm; detailed specifi-
cation
Ä on page 27.
 Wall thickness W = 100 – 235 mm
 50 – 230 mm distance to the ceiling slab
 ≥ 50 mm distance to load-bearing structural elements
 ≥ 200 mm distance between two dry mortarless installation kits
 Subsidence of the ceiling slab a ≤ 40 mm
For installation, follow the supplied installation manual.
Installation
Lightweight partition walls > Dry mortarless installation with installation ...
Fire damper Type FKRS-EU36
