5.6.3 Dry mortarless installation with fire batt
A
A
A
W
100
50
W
100
≥24
100
≥24
100 50
12,5 12,5
a ≥10
W ≥100
220
W
220
220
a
a = 40...400
100
≥24
50 x 60
a
2 x ∅DN + a + 80...800
∅DN + 80...800
2 x ∅DN + a + 80...800
∅DN + 80...800
∅DN + 80...800
∅DN + 80...800
40...400
40...400
40...400
①
࿆
࿇
࿇
Y
Y
②
③
①②③②
④
⑤
⑤
⑥
࿆࿇
③
⑥
②
②
࿆
࿇
⑦
࿆࿇
⑦
③
②
②
࿆
࿇
Fig. 21: Dry mortarless installation with fire batt
①
Extension piece (if required)
②
Fire protection coating
③
Coated mineral wool slabs, ≥ 140 kg/m³
④
Perimeter metal section
⑤
Dry wall screw (for cladding)
⑥
Trim panels
⑦
Mineral wool strips ≥ 80 kg/m³ (only when distance
a≤ 50 mm)
Ⓐ
Installation side
Ⓑ
Operating side
Note: Each fire damper must be suspended separately Ä 46.
