TSC DA200 Series

DA200/ DA300
Bar Code Printer Service Manual
15
3.5 Replacing the Black-mark Sensor Module
1. Please refer to the section 3.3 to
remove the lower cover.
2. Remove 1 screw and 1 connector
to replace the black-mark sensor
board.
3. Reassemble the parts in the
reverse procedure.
