DA200/ DA300
Bar Code Printer Service Manual
29
3.11 Linerless Cutter Module Installation (Option)
1. Open the printer top cover by
pressing up the top cover
open tabs located on each
side of the printer.
2. Remove the lower front panel.
3. Disengage the platen holder tabs by pulling out the right side and left side tabs.
Rotate the tabs into the forward position. (see picture below)
4. Take out the platen roller to
install the linerless platen
roller.
To Next Page
