TSC DA200 Series

DA200/ DA300
Bar Code Printer Service Manual
30
5. Remove 4 screws on the
printer lower cover.
6. Thread the linerless cutter
module 8-pin harness and
ground cable through the
front slot of lower inner
cover.
7. Connect the linerless cutter
module harness connector
(8-pin white socket) &
ground cable on the printer
main board.
