TSC MB340T Series Service Manual

3
Rear View
1. External label entrance chute
2. Power switch
3. USB interface (High speed mode)
4. Slot-in Wi-Fi or GPIO interface (Option)
5. USB host
6. RS-232C interface
7. Ethernet interface
8. Power cord socket
Note:
The interface picture here is for reference only. Please refer to
the product specification for the interfaces availability.
1
2
8
4
3
5
6
7
