TSC ME240 Service Manual

16
16
3.5 Replacing the Power Supply Unit
1. Refer to section 3.4 to remove the main board.
2. Disconnect two connectors from the power switch.
3. Take off the power supply cover (black mylar). Disconnect two connectors and
remove four screws on the power supply unit.
3. Replace the power supply unit.
4. Reassemble the parts in the reverse procedures.
Screws
Screws

TSC ME240 Specifications

General

Resolution	203 dpi / 300 dpi
Operating Temperature	5°C to 40°C (41°F to 104°F)
Print Method	Thermal Transfer & Direct Thermal
Interface	USB
Power Supply	AC 100-240V, 50/60Hz
Humidity	20% to 85% RH (non-condensing)
