4.2 Print Head Pressure Adjustment Knob
There are two conditions that will need to adjust the print head pressure.
1. Print with thick media
If the media thickness is larger than 0.19 mm, the larger pressure is required to get
good quality printout.
2. Print with narrow media
If the media width is less than 4 inch wide the print head pressure will need to be
adjusted to avoid ribbon wrinkle
There are 5 levels of pressure for adjustment. Level 1 is the minimum pressure and level 5 is
the maximum pressure.
For example, if the label width is 4 inch, adjust both print head pressure adjustment knobs to
the same level. If the label is less than 2 inch wide, increase the left side print head pressure
by rotating the adjustment knob clockwise and decrease the right side pressure by rotating
the adjustment knob counter-clockwise to level 1.

TSC ME240 Specifications

General

Resolution	203 dpi / 300 dpi
Operating Temperature	5°C to 40°C (41°F to 104°F)
Print Method	Thermal Transfer & Direct Thermal
Interface	USB
Power Supply	AC 100-240V, 50/60Hz
Humidity	20% to 85% RH (non-condensing)
