TSC ME240 Service Manual

19
19
6. Take out the platen bushing, platen roller assembly and replace a new platen
roller assembly.
7. Reassemble the parts in the reverse procedures.
Note:
For regular label
For thick label
(Thickness is 0.19 mm)
Platen roller assembly
Right side
bushing
Indicator (The default position is set

TSC ME240 Specifications

General

Resolution	203 dpi / 300 dpi
Operating Temperature	5°C to 40°C (41°F to 104°F)
Print Method	Thermal Transfer & Direct Thermal
Interface	USB
Power Supply	AC 100-240V, 50/60Hz
Humidity	20% to 85% RH (non-condensing)
