27
27
5. Loosen the connector before install the flat cable.
6. Connect the flat cable between the Centronics parallel interface board and the main
board.
7. Connect the 5-pin cable between the Centronics parallel interface board and main board.
8. Reassemble the parts in the reverse procedures.
