40
40
Adjust the print head pressure adjustment knob
The print head pressure adjustment knob has 5
levels of settings. Clockwise direction adjustment
is to increase the print head pressure. Counter
Clockwise adjustment can decrease the print head
pressure.
If the wrinkle on the label starts from the lower left
side to upper right side, please do following
adjustment.
1. Decrease the right side print head pressure
adjustment knob setting 1 level per each
adjustment then print the label again to check if
wrinkle is gone.
2. If the right side print head adjustment knob
setting has been set to index 1 (the lowest
pressure index), please increase the left side
print head pressure.
3. If the wrinkle can’t be avoided, please contact
the Customer Service Department of your
purchased reseller or distributor for service.
Adjust the print head pressure adjustment knob
The print head pressure adjustment knob has 5
levels of settings. Clockwise direction adjustment is
to increase the print head pressure. Counter
Clockwise adjustment can decrease the print head
pressure.
If the wrinkle on the label starts from the lower right
side to upper left side, please do following
adjustment.
1. Decrease the left side print head pressure
adjustment knob setting 1 level per each
adjustment then print the label again to check if
wrinkle is gone.
2. If the left side print head adjustment knob level
has been set to index 1 (the lowest index), please
increase the right side print head pressure.
3. If the wrinkle can’t be avoided, please contact the
Customer Service Department of your purchased
reseller or distributor for service.
Left knob
Right knob
