TSC PRINTRONIX AUTO ID TC200 Series - Loading the Fan-Fold Media

17
3.5 Loading the Fan-fold Media
1. Open the printer top cover then insert the fan-fold
media through the external label entrance chute.
2. Separate and hold open the media holders.
Note: Press down the media holder lock switch
to hold the media firmly.
3. Hold the top cover and press the top cover support
to disengage the top cover support with lower inner
cover, then gently close the top cover.
