TSC PRINTRONIX AUTO ID TC200 Series User Manual

4
1.1.1 Printer Optional Features
The printer offers the following optional features.
Product option feature
User
option
Dealer
option
Factory
option
Peel-off kit
Paper length: 1” ~ 6”
Note:
This peel-off module is supported for the thermal/ plain label only.
V
Regular cutter (full cut guillotine cutter)
Media thickness: 0.06~ 0.19 mm
Media length: 1” ~ max. length
Max. width: 110 mm
Media type: receipt and label liner w/o glue
Note: Except for the linerless cutter, all regular/heavy duty/care label cutters DO NOT cut on
media with glue.
V
KP-200 Plus keyboard display unit
V
KU-007 Plus programmable smart keyboard
V
External roll mount with 3” core label spindle
V
Sleeve adapter
V
External Bluetooth module (serial interface)
V
802.11 b/g/n wireless module (serial interface)
V
Parallel port for TC210/TC310 series (replace USB host)
V
Real time clock & Buzzer
V

TSC PRINTRONIX AUTO ID TC200 Series Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi (8 dots/mm)
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Print Speed	6 IPS (152 mm/s)
Max Print Width	4.09" (104 mm)
Connectivity	USB 2.0, RS-232
Media Handling	fan-fold, continuous
Media Type	Roll-fed or fan-fold
Media Width	1.0 to 4.64 inches
Media Core Diameter	1 inch (25.4 mm) or 1.5 inches (38.1 mm)
Media Max Roll Diameter	5 inches (127 mm)
Ribbon Width	1.57 inches (40 mm) to 4.33 inches (110 mm)
Ribbon Core Diameter	0.5 inches
Ribbon Length	984 feet (300 meters)
Power	100-240V AC, 50-60 Hz
Supported Barcode Types	Data Matrix, QR Code
