3.3 Loading the Ribbon

1. Open the printer’s top cover and lift the top cover to

the maximum open angle.

2. Open the ribbon access cover and the media cover.

3. Insert the ribbon right side onto the supply hub.

Align the notches on the left side and mount onto

the spokes.

4. Insert the paper core right side onto the rewind

hub. Align the notches on the left side and mount

onto the spokes.
