TSC PRINTRONIX AUTO ID TC200 Series User Manual

6
1.4 Ribbon Specification
Ribbon Specifications
Ribbon outside diameter
Max. 40 mm OD
Ribbon length
110 meter
Ribbon core inside diameter
0.5” ID core
Ribbon width
40 mm ~110 mm
Ribbon wound type
Ink coated outside wound
1.5 Media Specification
Media Specifications
Media roll capacity
Max. 5” OD
Media core diameter
1” & 1.5 ID core
Media type
Continuous, die-cut, black mark, external fan-fold, notch
Media wound type
Outside wound
Media width
20 mm ~ 112 mm
Media thickness
0.06 mm ~ 0.19 mm
Label length
10 mm ~ max. print length
Label length (peeler mode)
25.4 mm ~ 152.4 mm (1” ~ 6”)
Label length (cutter mode)
25.4 ~ max. print length
Black mark
Min. 8 mm (W) x 2 mm (H)
Gap height
Min. 2 mm

TSC PRINTRONIX AUTO ID TC200 Series Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi (8 dots/mm)
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Print Speed	6 IPS (152 mm/s)
Max Print Width	4.09" (104 mm)
Connectivity	USB 2.0, RS-232
Media Handling	fan-fold, continuous
Media Type	Roll-fed or fan-fold
Media Width	1.0 to 4.64 inches
Media Core Diameter	1 inch (25.4 mm) or 1.5 inches (38.1 mm)
Media Max Roll Diameter	5 inches (127 mm)
Ribbon Width	1.57 inches (40 mm) to 4.33 inches (110 mm)
Ribbon Core Diameter	0.5 inches
Ribbon Length	984 feet (300 meters)
Power	100-240V AC, 50-60 Hz
Supported Barcode Types	Data Matrix, QR Code
