TSC PRINTRONIX AUTO ID TC200 Series User Manual

55
UL 60950-1(2nd Edition)
CSA C22.2 No. 60950-1-07(2nd Edition)
EN 60950-1
GB 4943.1
GB 9254, Class B
GB 17625.1
Energy Star for Imaging Equipment Version 2.0
Note: There may have certification differences in the series models, please refer to product label for accuracy.
Important safety instructions:
1. Read all of these instructions and keep them for later use.
2. Follow all warnings and instructions on the product.
3. Disconnect the power plug from the AC outlet before cleaning or if fault happened.
Do not use liquid or aerosol cleaners. Using a damp cloth is suitable for cleaning.
4. The mains socket shall be installed near the equipment and easily accessible.
5. The unit must be protected against moisture.
6. Ensure the stability when installing the device, Tipping or dropping could cause damage.
7. Make sure to follow the correct power rating and power type indicated on marking label
provided by manufacture.
8. Please refer to user manual for maximum operation ambient temperature.
WARNING:
Hazardous moving parts, keep fingers and other body parts away.

TSC PRINTRONIX AUTO ID TC200 Series Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi (8 dots/mm)
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Print Speed	6 IPS (152 mm/s)
Max Print Width	4.09" (104 mm)
Connectivity	USB 2.0, RS-232
Media Handling	fan-fold, continuous
Media Type	Roll-fed or fan-fold
Media Width	1.0 to 4.64 inches
Media Core Diameter	1 inch (25.4 mm) or 1.5 inches (38.1 mm)
Media Max Roll Diameter	5 inches (127 mm)
Ribbon Width	1.57 inches (40 mm) to 4.33 inches (110 mm)
Ribbon Core Diameter	0.5 inches
Ribbon Length	984 feet (300 meters)
Power	100-240V AC, 50-60 Hz
Supported Barcode Types	Data Matrix, QR Code
