TSC TA310 - Mechanism and Component Replacement; Replacing the Print Engine Mechanism

TA210/ TA310/ TA200/ TA300
Bar Code Printer Service Manual
9
3. MECHANISM
Please turn off the power switch and unplug the power adapter before replacing parts.
3.1 Replacing the Print Engine Mechanism
1. Turn the printer upside down to
remove the four screws.
2. Disengage the interface cover
tabs on the bottom of the
printer for removing the
interface cover.
3. Open the printer top cover by
pressing the top cover open
tabs located on each side of
the printer. Take out the
interface cover.
Screws
Screws
Tabs
Interface cover
