TA210/ TA310/ TA200/ TA300
Bar Code Printer Service Manual
10
4. Push the print head release
button to open the print head
mechanism.
5. Remove the lower front panel.
6. Remove/Replace the print
engine mechanism.
7. Reassemble the parts in the
reverse procedure.
Note:
For more detail about print
engine mechanism, please refer
to next page.
Print engine
mechanism
