TSC TE210 Series Service Manual

43
TE200/TE210/TE300/TE310 Series
Bar Code Printer Service Manual
5. MAINTENANCE
This session presents the clean tools and methods to maintain your printer.
1. Please use one of following material to clean the printer.
 Cotton swab (Head cleaner pen)
 Lint-free cloth
 Vacuum / Blower brush
 100% ethanol
2. The cleaning process is described as following
Printer Part
Method
Interval
Print Head
1. Always turn off the printer
before cleaning the print head.
2. Allow the print head to cool for
a minimum of one minute.
3. Use a cotton swab (Head
cleaner pen) and 100% ethanol
to clean the print head surface.
Clean the print head when changing a
new label roll
Platen Roller
1. Turn the power off.
2. Rotate the platen roller and
wipe it thoroughly with 100%
ethanol and a cotton swab, or
lint-free cloth.
Clean the platen roller when changing
a new label roll
Tear Bar/Peel
Bar
Use the lint-free cloth with 100%
ethanol to wipe it.
As needed
Sensor
Compressed air or vacuum
Monthly

TSC TE210 Series Specifications

General

Resolution	203 DPI
Print Speed	6 IPS
Print Method	Thermal transfer / Direct thermal
Processor	32-bit RISC CPU
Interface	USB 2.0, RS-232, Ethernet
Scan Rate	N/A (Barcode printer, not a barcode reader)
Barcode Resolution	N/A (Barcode printer, not a barcode reader)
Supported Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-13, EAN-8, Interleaved 2 of 5, Codabar, POSTNET
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
Humidity	25 ~ 85% non-condensing (Operating)
Power Consumption	100-240V AC, 50/60Hz
