TSC TE210 Series

2
TE200/TE210/TE300/TE310 Series
Bar Code Printer Service Manual
1.2 Interior View
1. Printer top cover
8. Ribbon supply spindle
2. Ribbon supply hub
9. Platen roller
3. Ribbon rewind hub
10. Black mark sensor
4. Ribbon rewind spindle
11. Gap sensor
5. Print head release button
12. Media guide
6. Fixing tabs
13. Media guide hub
7. Media supply spindle
14. Print head
WARNING
HAZARDOUS MOVING PARTS
KEEP FINGERS AND OTHER
BODY PARTS AWAY
OPEN
6
5
1
3
4
7
13
12
8
14
9
11
2
10
