TE200/TE210/TE300/TE310 Series
Bar Code Printer Service Manual
3. MECHANISM
Please turn off the power switch and unplug the power adapter before replacing parts.
3.1 Replacing the Print Engine Mechanism
1. Open the printer top cover by
pressing the top cover open
tabs located on each side of
the printer.
2. Remove the four screws on
media holder and disengage
it.
3. Remove the two screws on
the print engine which
besides the platen roller.
