TSC TE210 Series

37
TE200/TE210/TE300/TE310 Series
Bar Code Printer Service Manual
3.14 Replacing the Wi-Fi module Assembly
(TE210/TE310 Series option)
1. Please refer to the section 3.1
to remove the print engine.
2. Remove the three screws on
lower print engine right side
cover as indicated and open
it.
3. Remove the Wi-Fi module
assembly cable on main
board as indicated.
Screws
