TE200/TE210/TE300/TE310 Series
Bar Code Printer Service Manual
3.8 Installing the Cutter Module (TE210/TE310 Series option)
1. Open the printer top cover by
pressing the top cover open
tabs located on each side of the
printer.
2. Push the print head release
button to open the print head
mechanism.
3. Remove the lower front panel.
4. Insert the cable and ground line
of cutter module through the
hole as indicated to the main
board.
5. Remove the four screws on
media holder and disengage it.
To Next Page
