20
TE200/TE210/TE300/TE310 Series
Bar Code Printer Service Manual
4. Reassemble the parts in the reverse
procedure.
3.6 Replacing the Platen Roller Assembly
1. Open the printer top cover then push
the print head release button to open
the print head mechanism.
2. Remove the lower front panel.
3. Disengage the platen roller by pulling out the tabs located on each side. Rotate
the tabs into the upward position. (see pictures below)
Note: The white mark is the default setting of tab position
To Next Page
