TE200/TE210/TE300/TE310 Series
Bar Code Printer Service Manual
4. Pulling upward to remove/replace
the platen roller assembly.
5. Reassemble the parts in the
reverse procedure.
3.7 Replacing the Print Head Module
1. Open the printer top cover and press
the print head release button to open
the print head mechanism.
Default setting
Platen roller module
