TE200/TE210/TE300/TE310 Series
Bar Code Printer Service Manual
5. Push the front tab of the print head bracket to the right side and open the print
head bracket as pictured.
6. Remove/Replace the print head assembly.
7. Reassemble the parts in the reverse procedures.
Note: If the print quality became poor after changed the print head, please
switch the calibration on the print head engine to adjust the print quality.
Print head assembly
Front tab

TSC TE210 Series Specifications

General

Resolution	203 DPI
Print Speed	6 IPS
Print Method	Thermal transfer / Direct thermal
Processor	32-bit RISC CPU
Interface	USB 2.0, RS-232, Ethernet
Scan Rate	N/A (Barcode printer, not a barcode reader)
Barcode Resolution	N/A (Barcode printer, not a barcode reader)
Supported Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-13, EAN-8, Interleaved 2 of 5, Codabar, POSTNET
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
Humidity	25 ~ 85% non-condensing (Operating)
Power Consumption	100-240V AC, 50/60Hz
