TSC TE210 Series Service Manual

42
TE200/TE210/TE300/TE310 Series
Bar Code Printer Service Manual
Wrinkle problem
* Ribbon installation is incorrect.
* Media installation is incorrect.
* Print density is incorrect.
* Media feeding is incorrect.
* Please set the suitable density to have
good print quality.
* Make sure the label guide touch the edge
of the media guide.
Gray line on the blank
label
* The print head is dirty.
* The platen roller is dirty.
* Clean the print head.
* Clean the platen roller.
Irregular printing
* The printer is in Hex Dump mode.
* Turn off and on the printer to skip the
dump mode.

TSC TE210 Series Specifications

General

Resolution	203 DPI
Print Speed	6 IPS
Print Method	Thermal transfer / Direct thermal
Processor	32-bit RISC CPU
Interface	USB 2.0, RS-232, Ethernet
Scan Rate	N/A (Barcode printer, not a barcode reader)
Barcode Resolution	N/A (Barcode printer, not a barcode reader)
Supported Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-13, EAN-8, Interleaved 2 of 5, Codabar, POSTNET
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
Humidity	25 ~ 85% non-condensing (Operating)
Power Consumption	100-240V AC, 50/60Hz
