2.2
Pin
Configurat
ion
USB
PIN
CONFIGU
RA
TI
ON
1
N/C
2
D-
3
D+
4
GND
TE210/TE310 Se
ries on
ly:
RS
-232
C
PIN
CONFIGU
RA
TI
ON
1
+5 V
2
TXD
3
RXD
4
CTS
5
GND
6
RTS
7
N/C
8
RTS
9
N/C
USB Device
PIN
CONFIGU
RA
TI
ON
1
N/C
2
D-
3
D+
4
GND
USB Host
PIN
CONFIGU
RA
TI
ON
1
5V
2
D-
3
D+
4
GND
