19
TE200/TE210/TE300/TE310 Series
Bar Code Printer Service Manual
3.5 Replacing the Black-mark Sensor Module
1. Please refer to the section 3.3 to
remove the stepping motor module.
2. Open the Mylar film cover and
remove the screw on the black-mark
sensor module.
3. Remove/replace the black-mark
sensor module.
Mylar film
Black-mark sensor

Other manuals for TSC TE310 Series

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TSC TE310 Series and is the answer not in the manual?

TSC TE310 Series Specifications

General IconGeneral
Resolution203 dpi / 300 dpi
Print MethodThermal transfer / Direct thermal
InterfaceEthernet
Power SupplyAC 100-240V, 50/60Hz
Operating Temperature41°F to 104°F (5°C to 40°C)
Storage Temperature-40 ~ 60°C (-40 ~ 140°F)
Humidity20% to 85% (non-condensing)
