TE200/TE210/TE300/TE310 Series
Bar Code Printer Service Manual
3.8 Installing the Cutter Module (TE210/TE310 Series option)
1. Open the printer top cover by
pressing the top cover open
tabs located on each side of the
printer.
2. Push the print head release
button to open the print head
mechanism.
3. Remove the lower front panel.
4. Insert the cable and ground line
of cutter module through the
hole as indicated to the main
board.
5. Remove the four screws on
media holder and disengage it.

TSC TE310 Series Specifications

General

Resolution	203 dpi / 300 dpi
Print Method	Thermal transfer / Direct thermal
Interface	Ethernet
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
Humidity	20% to 85% (non-condensing)
