TSC TE310 Series Service Manual

20
TE200/TE210/TE300/TE310 Series
Bar Code Printer Service Manual
4. Reassemble the parts in the reverse
procedure.
3.6 Replacing the Platen Roller Assembly
1. Open the printer top cover then push
the print head release button to open
the print head mechanism.
2. Remove the lower front panel.
3. Disengage the platen roller by pulling out the tabs located on each side. Rotate
the tabs into the upward position. (see pictures below)
Note: The white mark is the default setting of tab position

TSC TE310 Series Specifications

General

Resolution	203 dpi / 300 dpi
Print Method	Thermal transfer / Direct thermal
Interface	Ethernet
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
Humidity	20% to 85% (non-condensing)
