TSC TE310 Series Service Manual

29
TE200/TE210/TE300/TE310 Series
Bar Code Printer Service Manual
6. Reassemble the parts in the reverse
procedures.
3.11 Replacing the Print Head Open Sensor Assembly
1. Please refer to the section 3.1 to
remove the print engine.
2. Disconnect the three screws to
remove the right side lower cover.
3. Remove the print head open sensor
by disengage the screw and cable
(black) as indicated.
Screws

TSC TE310 Series Specifications

General

Resolution	203 dpi / 300 dpi
Print Method	Thermal transfer / Direct thermal
Interface	Ethernet
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
Humidity	20% to 85% (non-condensing)
