TSC TE310 Series Service Manual

21
TE200/TE210/TE300/TE310 Series
Bar Code Printer Service Manual
4. Pulling upward to remove/replace
the platen roller assembly.
5. Reassemble the parts in the
reverse procedure.
3.7 Replacing the Print Head Module
1. Open the printer top cover and press
the print head release button to open
the print head mechanism.
Default setting
Platen roller module

TSC TE310 Series Specifications

General

Resolution	203 dpi / 300 dpi
Print Method	Thermal transfer / Direct thermal
Interface	Ethernet
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
Humidity	20% to 85% (non-condensing)
