4
TE200/TE210/TE300/TE310 Series
Bar Code Printer Service Manual
2. ELECTRONICS
2.1 Summary of Board Connectors
Main board for TE200/TE300 Series
2
3
4
5
6
7
11
9
12
14
13
10
8
15
1
