TSC TE310 Series Service Manual

27
TE200/TE210/TE300/TE310 Series
Bar Code Printer Service Manual
5. Connect the cable to the socket
on main board as indicated.
6. Push down the peeler module
and fix on the lower front panel
location hole.
7. Close the print head mechanism
and printer cover.
8. Close the media cover and
complete peeler module
installation.
9. Reassemble the parts in the
reverse procedures.

TSC TE310 Series Specifications

General

Resolution	203 dpi / 300 dpi
Print Method	Thermal transfer / Direct thermal
Interface	Ethernet
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
Humidity	20% to 85% (non-condensing)
