TSC TE310 Series Service Manual

32
TE200/TE210/TE300/TE310 Series
Bar Code Printer Service Manual
3. Remove the screw on the
Encoder assembly.
4. Push the latch on ribbon base hinge to left side, pull out the ribbon base
hinge and remove the Encoder assembly.
Screw
PUSH
Slot

TSC TE310 Series Specifications

General

Resolution	203 dpi / 300 dpi
Print Method	Thermal transfer / Direct thermal
Interface	Ethernet
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
Humidity	20% to 85% (non-condensing)
