22
22
TTP-246M/344M Bar Code Printer
Service Manual
3.12.1 TTP-246M & 344M PCB Top Side
JP23
JP37
JP18
JP22
JP17
JP19
JP20
JP21
JP12
JP15
JP13
JP36
JP5
JP8
JP11
JP16
JP10
JP9
Cutter Driver IC 3953
JP33
JP34
JP2
JP36
JP1
