TTP-246M/344M Bar Code Printer
Service Manual
4. Mechanism
4.1 Remove Covers, LCD Panel and Lower Front Panel
1. Open Top Right Side Cover.
2. Loosen four screws to separate the Top Right Side Cover and Main Frame.
Top Right Side Cover
Screws
Screws
