TTP-246M/344M Bar Code Printer
Service Manual
4.16 Peeler Kit Installation (Option)
 Checklist:
1. Open the lower front panel and the printer right side cover.
Peel off sensor assembly
Peel off roller
Left side spring leaf
Right side spring leaf
Washer
Screw
Peel off roller
right side bush
Peel off roller
left side bush
