TTP-246M/344M Bar Code Printer
Service Manual
7. Reassemble in the reverse procedures after replacing.
4.12 Replacing Gap / Black Mark Sensor
1. Disconnect Gap/Black Mark Sensor harness from Main PCB.
2. Remove the 2 screws these are connected the Gap/Black Mark sensor and plate.
3. Loosen two screws on the Gap/Black Mark Sensor Assembly.
E
D
C
B
A
M4 screw
Knob
F
Screws
