TTP-246M/344M Bar Code Printer
Service Manual
3. Press the button (MENU, SELECT) under the message “Fwd.” to feed the label forward a
little bit. Press the button (PAUSE, EXE./INC.) under the message “Rev.” to reverse the
label if it is necessary for adjusting the label. Pull the liner outward tightly. Close the Print
Head Lift Lever.
4. Close the lower front panel. Pull the label through the Peel-off panel upper opening; pull the
liner through the Peel-off panel upper opening.
Label
Liner
Peel-off roller
Liner
