TSC TTP-247 User Manual

40
Check if supply is loaded
correctly.
Reload the supply.
Ribbon and media are
incompatible.
Change the ribbon or label
combination.
Check if dust or adhesives are
accumulated on the print head.
Clean the print head.
Check if print density is set
properly.
Adjust the print density and print
speed.
Check print head test pattern if
head element is damaged.
Run printer self-test and check
the print head test pattern if
there is dot missing in the
pattern.

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
